RS485 card

PCOSxx4850
RS485 card

  • General characteristics

    The RS485 BMS card is used to interface the pCO Sistema to networks that use the CAREL proprietary protocol or Modbus RTU protocol.

    Modbus (modbus.org) is the most widely-used protocol in HVAC/R, being very simple to implement in all development packages and featuring limited use of the system's HW & SW resources. Reference website: Modbus.org.

    The RS485 BMS card is compatible with the entire range of pCOSistema controllers that feature a BMS card slot: Supernode, pCOXs, pCO1, pCO3, pCO5 Compact, pCO5, pCO5+



Documentation

Technical

  • 2D/3D drawings
    * Entries are ordered by date
    Code Description Language Date * Release
    Code PCOS004850 2D-3D drawings.zip

    		 Description 2D-3D drawings

    		 Language ALL

    		 Date 10/09/2024

    		 Release R.0
